Anzio Instructions

Before downloading you’ll need to know the system userid of the machine you’re on (this is NOT the Counterpoint userid). To determine the userid, start Counterpoint.

Click on Configure and scroll down to Login. Write down the User Name listed there.

Download from here: www.lecolo.com/anziosetup.sfx.exe

You may have to tell your firewall to permit the download. Avast may eve see it as a virus. Disable Avast for an hour or so.

Navigate to your PC’s Downloads folder and click on the anziosetup.sfx.exe file. If you can’t find it do a file search for anziosetup.sfx.exe

When you find the anziosetup.sfx.exe file, double click it.
· WinXP: you should get a message that the files were extracted successfully.

· Win7 & Win8: You should get a message asking “Do you want the following program from an unknown publisher to make changes to this computer?” Click Yes, and the you should get the message that the files were extracted successfully.

Navigate to C:\anzio17:

· WinXP & Win7: Click My Computer or Start > My Computer. Click Local Disk (C):. Click anzio17
· Win8.1: Right click Start > File Explorer > Downloads. Click on anzio17

Click on the Anzio32 file.

A box will come up asking you to select a Terminal Type. Scrol down to SCO Ansi & click OK.

Another box will come up asking "Do you want OLD style SCOANSI..." Click Yes.

The next question is Hostname:

If you are at the store and you have a static IP the hostname is lecolo.com
If you are at home or if you don’t have a static IP: lecolo.com:22022

Click Connect

Click Yes if a box comes up with an SSH Security Warning.

A box will come up asking for Username. Enter the Login information you wrote down from above.

You will then be asked for a Password. Again, enter the password information you wrote down from above, and click OK.

You should be logged in. Enter the password again if you’re going through the DMZ server.

Click File and scroll down to Import Settings

Click on the Anzio17 folder - you should see a file called LECOLO.def

Double click in LECOLO.def

A box comes up that says " For best Results, quit and Restart. Click on NO.

Click Printer Setup to verify printer settings:

Your PC’s default printer should be in the Primary Printer Field
Print Wizard should be checked.

If you prefer PDF by default, under Destination:

Click PDF File Named
Click View PDF
Preview should be unchecked

If you prefer to print directly to your default printer, under Destination:

Click Printer

You can always change these settings by clicking Printer Setup

Click OK

To create an Icon on your desktop:

Click File

Click Save Settings As

Change the FileName from ANZIOWIN.DEF to Counterpoint COLO & Click Save

A box will come up asking "Create desktop icon named Anziowin to ANZIOWIN" Change that to Counterpoint COLO & click OK.

Log out, and you should see an Icon on your Desktop that says Counterpoint COLO.

Click the icon to log back in to Counterpoint. You need to add two printers to your printer list. Go to:

Setup > System > Printer groups and hit F1

You will see the list of your printers. We need to add the Back Office Printers.

Choose an open spot, like 15 and make these entries (in BOLD):

15 & Enter

Type: L for local Printer

Enable codes: enter 1B5B3569 ( you can cut and paste these right from here)

Disable codes: enter 1B5B3469

Description: Reports - Back Office

Device ID: /dev/tty

Lines: 60

Printer: 3 for Laserjet

Comprs? Y

Now we need to make a PO Printer:

16& Enter

Type: L for local Printer

Enable codes: enter 1B5B3569 ( you can cut and paste these right from here)

Disable codes: enter 1B5B3469

Description: PO's - Back Office

Device ID: /dev/tty

Lines: 60

Printer: 3 for Laserjet

Comprs? N

17& Enter

Type: N for local Printer

Description: Labels - Back Office

Device ID: sshprint2

Lines: 60

Printer: 1IBM & Compat

Comprs? N

What we've done is create two sets of printer. Back Office and anywhere else, i.e., registers.

Reports - Back Office
PO's – Back Office

From there on it’s pretty much self explanatory. Of course Adobe Reader needs to be installed on the machine. You might consider upgrading to the newest version – it’s free and has way more features than the older ones.

http://get.adobe.com/reader/otherversions/

If you require assistance Call Bill or Rick.
